Features
- = Powered by GeForce® GTX 1050
- = Integrated with 3GB GDDR5 memory
- = WINDFORCE 2X with Blade Fan Design
- = Support up to 8K display @60Hz
- =
One-click Super Overclocking
Core Clock
- = Boost: 1582 MHz/ Base: 1442 MHz in OC Mode
- = Boost: 1556 MHz/ Base: 1417 MHz in Gaming
Graphics Processing
GeForce® GTX 1050
Core Clock
Boost: 1582 MHz/ Base: 1442 MHz in OC Mode
Boost: 1556 MHz/ Base: 1417 MHz in Gaming
CUDA® Cores
768
Memory Clock
7008 MHz
Memory Size
3 GB
Memory Type
GDDR5
Memory Bus
96 bit
Card Bus
PCI-E 3.0 x 16
Digital max resolution
7680x4320
Multi-view
3
Card size
H=36 L=191 W=111 mm
PCB Form
ATX
DirectX
12
OpenGL
4.5
Recommended PSU
300W
Power Connectors
N/A
Output
Dual-link DVI-D *1
HDMI-2.0b*1 (Max Resolution: 4096x2160 @60 Hz)
Display Port-1.4 *1 (Max Resolution: 7680x4320 @60 Hz)
* The entire materials provided herein are for reference
only. GIGABYTE reserves the right to modify or revise the content at anytime
without prior notice.
* Advertised performance is based on maximum theoretical interface values from
respective Chipset vendors or organization who defined the interface
specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for
system usage and therefore the actual memory size is less than the stated
amount.
